Int xeon-g 6530 cpu for hpe
Conectează-te ca să te putem notifica când primești un răspuns
Specificații
Avx-512 Fused Multiply-add (fma) Units:
- 2
Commodity Classification Automated Tracking System (ccats):
- 740.17B1
Cpu-cores:
- 6
Cpu-series:
- Xeon Gold
Discrete Graphics Card:
- No
Discrete Graphics Card Model:
- Not available
Dts Max:
- 91 °C
Embedded Options Available:
- Yes
Execute Disable Bit:
- Yes
Export Control Classification Number (eccn):
- 5A992C
Harmonized System (hs) Code:
- 8542310001
High Priority Core Frequency:
- 2.3 GHz
High Priority Cores:
- 12
Intel 64:
- Yes
Intel Software Guard Extensions (intel Sgx):
- Yes
Intel Trusted Execution Technology:
- Yes
Intel Virtualization Technology (vt-x):
- Yes
Intel Virtualization Technology For Directed I/o (vt-d):
- Yes
Intel Vt-x With Extended Page Tables (ept):
- Yes
Intel® Advanced Matrix Extensions (amx):
- Yes
Intel® Aes New Instructions (intel® Aes-ni):
- Yes
Intel® Boot Guard:
- Yes
Intel® Control-flow Enforcement Technology (cet):
- Yes
Intel® Crypto Acceleration:
- Yes
Intel® Data Streaming Accelerator (dsa):
- 1 default devices
Intel® Deep Learning Boost (intel® Dl Boost) On Cpu:
- Yes
Intel® Hyper Threading Technology (intel® Ht Technology):
- Yes
Intel® On Demand Feature Activation:
- Yes
Intel® Os Guard:
- Yes
Intel® Platform Firmware Resilience Support:
- Yes
Intel® Quickassist Software Acceleration:
- Yes
Intel® Resource Director Technology (intel® Rdt):
- Yes
Intel® Run Sure Technology:
- Yes
Intel® Speed Select Technology - Base Frequency (intel® Sst-bf):
- Yes
Intel® Speed Select Technology – Core Power:
- Yes
Intel® Speed Select Technology – Turbo Frequency:
- Yes
Intel® Speed Shift Technology:
- Yes
Intel® Total Memory Encryption:
- Yes
Intel® Total Memory Encryption - Multi Key:
- Yes
Intel® Transactional Synchronization Extensions:
- Yes
Intel® Turbo Boost Technology:
- 2.0
Intel® Upi Speed:
- 20 GT/s
Intel® Volume Management Device (vmd):
- Yes
Launch Date:
- Q4'23
Low Priority Core Frequency:
- 1.9 GHz
Low Priority Cores:
- 20
Market Segment:
- Server
Maximum Enclave Size Support For Intel® Sgx:
- 128 GB
Maximum Internal Memory:
- 4 TB
Maximum Internal Memory Supported By Processor:
- 4 TB
Maximum Number Of Pci Express Lanes:
- 80
Memory Channels:
- Octa-channel
Memory Clock Speeds Supported By Processor:
- 4800 MHz
Memory Types Supported By Processor:
- DDR5-SDRAM
Mode-based Execute Control (mbe):
- Yes
Number Of Upi Links:
- 3
On-board Graphics Card:
- No
On-board Graphics Card Model:
- Not available
Package Carrier:
- E1A
Pci Express Slots Version:
- 5.0
Processor Ark Id:
- 237249
Processor Base Frequency:
- 2.1 GHz
Processor Boost Frequency:
- 4 GHz
Processor Cache:
- 160 MB
Processor Cache Type:
- L3
Processor Codename:
- Emerald Rapids
Processor Cores:
- 32
Processor Family:
- Intel® Xeon® Gold
Processor Generation:
- Intel Xeon Scalable 5th Gen
Processor Manufacturer:
- Intel
Processor Model:
- 6530
Processor Operating Modes:
- 64-bit
Processor Package Size:
- 77.5 x 56.5 mm
Processor Socket:
- LGA 4677 (Socket E)
Processor Threads:
- 64
Producator:
HPE
Scalability:
- 2S
Servicing Status:
- Baseline Servicing
Status:
- Launched
Stepping:
- A1
Supported Instruction Sets:
- AMX, AVX, AVX 2.0, AVX-512, SSE4.2
Tcase:
- 74 °C
Thermal Design Power (tdp):
- 270 W
Use Conditions:
- Server/Enterprise
Descriere
INT Xeon-G 6530 CPU for HPE
