D-link dgs-1100-24v2. switch type: managed, switch layer: l2. basic switching rj-45 ethernet ports type: gigabit ethernet (10/100/1000), basic switching rj-45 ethernet ports quantity: 24. full duplex. mac address table: 8000 entries, switching capacity: 4
Conectează-te ca să te putem notifica când primești un răspuns
Specificații
10g Support:
- No
Ac Input Frequency:
- 50/60 Hz
Ac Input Voltage:
- 100 - 240 V
Auto Mdi/mdi-x:
- Yes
Auto-negotiation:
- Yes
Basic Switching Rj-45 Ethernet Ports Quantity:
- 24
Basic Switching Rj-45 Ethernet Ports Type:
- Gigabit Ethernet (10/100/1000)
Broadcast Storm Control:
- Yes
Certification:
- FCC, CE, VCCI, C-Tick, BSMI, CCC
Compliance Certificates:
- BSMI, CB, CCC, cUL
Depth:
- 180 mm
Ethernet Lan Data Rates:
- 10,100,1000 Mbit/s
Flash Memory:
- 16 MB
Flow Control Support:
- Yes
Form Factor:
- 1U
Forwarding Rate:
- 35.71 Mpps
Full Duplex:
- Yes
Half Duplex:
- Yes
Head-of-line (hol) Blocking:
- Yes
Heat Dissipation:
- 54.3 BTU/h
Height:
- 44 mm
Igmp Snooping:
- Yes
Installed Sfp+ Modules Quantity:
- 0
Jumbo Frames:
- 9216
Jumbo Frames Support:
- Yes
Led Indicators:
- Yes
Link Aggregation:
- Yes
Loop Protection:
- Yes
Mac Address Table:
- 8000 entries
Mean Time Between Failures (mtbf):
- 424762 h
Networking Standards:
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x
Number Of Power Supply Units:
- 1
Number Of Vlans:
- 128
Operating Relative Humidity (h-h):
- 0 - 95%
Operating Temperature (t-t):
- 5 - 50 °C
Packet Buffer Memory:
- 4.1 MB
Port Mirroring:
- Yes
Power Consumption (max):
- 15.9 W
Power Over Ethernet (poe):
- No
Power Source:
- AC
Power Supply Included:
- Yes
Producator:
D-LINK
Product Colour:
- Black, Grey
Quality Of Service (qos) Support:
- Yes
Rack Mounting:
- Yes
Rate Limiting:
- Yes
Spanning Tree Protocol:
- Yes
Storage Relative Humidity (h-h):
- 0 - 95%
Storage Temperature (t-t):
- -40 - 70 °C
Sustainability Compliance:
- Yes
Switch Layer:
- L2
Switch Type:
- Managed
Switching Capacity:
- 4.8 Gbit/s
Virtual Lan Features:
- Port-based VLAN
Vlan Support:
- Yes
Web-based Management:
- Yes
Weight:
- 1.32 kg
Width:
- 280 mm
Descriere
D-Link DGS-1100-24V2. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x. Rack mounting, Form factor: 1U
