Chieftec core bbs-500s. total power: 500 w, ac input voltage: 100 - 240 v, ac input frequency: 47 - 63 hz. motherboard power connector: 24-pin atx, sata power cable length: 150,500 mm, peripheral (molex) power cable length: 150,500 mm. purpose: pc, power
Conectează-te ca să te putem notifica când primești un răspuns
Specificații
80 Plus Certification:
- 80 PLUS Gold
Ac Input Frequency:
- 47 - 63 Hz
Ac Input Voltage:
- 100 - 240 V
Atx Version:
- 2.3
Cabling Type:
- Non-Modular
Combined Power (+12v):
- 3.6 W
Combined Power (+5vsb):
- 12.5 W
Combined Power (-12v):
- 3.6 W
Cooling Type:
- Active
Cpu Power Cable Length:
- 65 cm
Cpu Power Connector (4+4 Pin):
- Yes
Depth:
- 150 mm
Fan Diameter:
- 12 cm
Floppy Disk Drive Connector:
- Yes
Floppy Drive Power Connector:
- 1
Harmonized System (hs) Code:
- 84733020
Height:
- 86 mm
Input Current:
- 8 A
Max Output Current (+12v):
- 0.3 A
Max Output Current (+12v1):
- 41 A
Max Output Current (+3.3v):
- 18 A
Max Output Current (+5v):
- 18 A
Max Output Current (+5vsb):
- 2.5 A
Max Output Current (-12v):
- 0.3 A
Motherboard Power Connector:
- 24-pin ATX
Number Of Fans:
- 1 fan(s)
Number Of Sata Power Connectors:
- 4
Package Weight:
- 2.06 kg
Pci Express Power Cable Length:
- 50 cm
Pci Express Power Connectors (6+2 Pin):
- 1
Peripheral (molex) Power Cable Length:
- 150,500 mm
Peripheral (molex) Power Connectors (4-pin):
- 3
Power Factor Correction (pfc) Type:
- Active
Power Protection Features:
- Over voltage, Overload, Short circuit
Power Supply Unit (psu) Form Factor:
- PS/2
Producator:
CHIEFTEC
Product Colour:
- Black
Purpose:
- PC
Sata Power Cable Length:
- 150,500 mm
Total Power:
- 500 W
Weight:
- 1.65 kg
Width:
- 140 mm
Descriere
Chieftec Core BBS-500S. Total power: 500 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, SATA power cable length: 150,500 mm, Peripheral (Molex) power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
